ac-dc switching power supply 12v LP-500-12 500W 37.5A single output Din-rail power supply with Digital display led driver
$64.29
196 in stock
Description
- Output Power: 401 – 500W
- Output Type: Single
- Model Number: LP-500-12
- Output Frequency: 47~63Hz
- Output Current: Cold starting current: 15A/115VAC 30A/230VAC
- is_customized: Yes
- Brand Name: makerele
- Input Voltage: 85~132VAC/176~264VAC(switchover) or 248~373VDC
- Place of Origin: Zhejiang China (Mainland)
- Rated Power: 450W
- Adjustable DC voltage range: 10.5~14V
- Voltage Tolerance: 2%
- Certification: CE ROHS
- Efficiency: 83%
- Over Load: 110%~150%
<li class="property-item" data-attr="" data-title=" Leakage current: <2mA/240VAC
|
|||||||||
|
|||||||||
|
|||||||||
Notice:
Please make sure the input voltage, output voltage and current in item specs when placing orders. Or we’ll arrange the one as the item specs says.
Model LP-500W-12 LP-500W-24 LP-500W-48
DC output voltage 12V 24V 48V
Output voltage tolerance 1% 1% 1%
Rated output current 37.5A 20.8A 10.4A
Output current range 0~37.5A 0~20.8A 0~10.4A
Output power 450W 499.2W 499.2W
Ripple and noise 120mVp-p 240mVp-p 300mVp-p
Adjustable DC voltage range 10.5~14V 20.5~26.5V 44.5~51V
Input voltage range 85~132VAC/176~264VAC(switchover) or 248~373VDC 47~63Hz
AC input current 9.5A/115VAC 4.8A/230VAC
Efficiency 83% 85% 86%
Impulse current Cold starting current: 15A/115VAC 30A/230VAC
Leakage current <2mA/240VAC
PROTECTION
Overload protection 110%~150%
Protection mode: cut off output and reset automatically
Overvoltage protection 14~18V 27~30V 51~54V
Protection mode: cut off output and reset automatically
ENVIRONMENT
Work temperature, humidity -10C~+50C;20%~90 %RH
Storage temperature, humidity -20C~+85C;10%~95 %RH
Shock resistance 10~500Hz,2G 10min./1 cycle,duration: 60min, each shaft
SAFETY
Voltage withstand capacity Input-output: 2KVAC Input-earth: 1.5KVAC Output-earth: 0.5KVAC
Insulation resistance Input-output, input-earth, output-earth: 100M Ohms/500VDC
STANDARD
Safety standard Conforms to UL1012
EMC standard Design refer to FCC Part15 J Conduction Class B
OTHERS
Weight 0.82KG
Package
Outline size 100*90*110mm(L*W*H)
According to your order,we can provide different cartons for you.
NOTE:
1. All parameters, except special situation, are measured under 230VAC voltage input and rated load at 25C.
2. The ripple and noise voltage are measured in condition that capacitance of 0.1 and 47 are applied to ends of 12inch twisted-pair of 20MHz bandwidth oscilloscope.
3. The tolerance is the sum of setting voltage error, voltage and current regulation factor.
Product Size:
-
1. Item will be shipped within 5-7 business days.
-
2. Delivery Time:
-
—-Via Air: Generally 1-3 working days
-
—-Via Express: Generally 3-7 working days.
-
—-Via China Post Air Mail: Generally 15-25 working days
-
—-Via Sea: According to the order.
-
3.If you have not received your shipment within 30 days from payment,Please contact with us,We will track the shipment and get back to you as soon as possible with a reply.
· We Ship to Worldwide, except APO/FPO.
· Items are shipped from China using Airmail, reach most of the countries within 10 to 20 business days.
· Delivery time depends on destination and other factors, it may takes up to 20 business days
· Noted: Fedex Maybe charge handling charges at your country, we are not responsible for this charges.
Payment:
Payment method on Aliexpress Check here help.aliexpress.com/payment_method.html
Warranty and Guarantee:
· 12 months Warranty. Buy with confidence!
· If you are not satisfied when you receive your item, please return it within 14 days for a replacement or money back. Please contact me before you return it.
· If item is defective in 3 months, We will send you a replacement without extra charges, or offer refund after we receive the defective item.
· If item is defective after 3 months, you can still send it back to us. We will send you a new one after receiving the defective item. But you have to pay the extra shipping fee
Other Policies:
· We are not responsible for any custom duty or import tax.
· We will leave POSITIVE FEEDBACK after receiving the payment. Please contact us if you are not satisfied with the item after receive it.
· All emails will be answered within 1 business day. If you do not receive our reply, please kindly re-sent your email and we will reply to you as soon as possible.
Serious Buyer Only! Please place bid only if you agree with all the terms
MingWei switching power supply factory is a set design, development, production in one of the high-tech professional manufacturers, the region is the first company to introduce Taiwan manufacturer of switch power supply technology, building in May 2001.
-
Custom Product Design
-
OEM/ODM
-
Profession in export service from Maker Electric
-
High quality Product, Affordable Price
Notes on choosing a switching power supply?
To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.
-
-
-
What are switching power supplies?
-
-
Switching power supplies input a commercial AC power supply (such as 110 VAC or 220 VAC), uses a high-speed semiconductor switching process to convert the input to high-frequency electric power, and yields a direct current (such as 24 VDC).
What about production process of switching power supply?
Maker Industrial and Trading Company started to run businiess since 2006, which is located in Wenzhou Yueqing – The world-famous city for low-voltage electric apparatus.We owns followed subsidiary corporations:
Yueqing Maker electric Co., Ltd. concentrates on Import and Export.
Yueqing MINGWEI Switching power supply FactoryMore than 20 years of production experience,focus on production and research and development of switch power supply.
|
||
|
