- Brand Name: makerele
- 500W”> Output Power: >500W
- Output Type: Single
- Model Number: SP-600-13.5
- Output Frequency: 47~63Hz
- Output Current: 44A
- is_customized: Yes
- Output Power: 600W
- Input Voltage: 88~264 VAC
- Rated Power: 600W
- Current Range: 0-44A
- AC Current: 7 A/115 VAC 3.5A/ 230 VAC
- Certification: CE ROHS
- Setup,Rise,Hold Time: 800ms, 50ms, 16ms at full load
- Safety Standard: Design refer to UL1012
- Isolation Resistance: I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
- Safety standards: Design refer to UL1950,CSA22.2,IEC60950
Working Temp., Humidity:-10~+65,20%~90 %RH
Please make sure the input voltage, output voltage and current in item specs when placing orders. Or we’ll arrange the one as the item specs says.
Voltage Range 88 –264VAC 47 –63Hz
AC Current 7A /115V, 3.5A /230V
Inrush Current 18A /115V, 36A /230V
Leakage Current 3.5 mA/240VAC
Over Load 101~115%(HSCN-600-5); 110%~135%(HSCN-600-1); HSCN-600-15; (HSCN-600-18;HSCN-600-24; HSCN-600-48)
Protection type: Current limiting, delay shut down o/p voltage, re-power on to recover
Over Voltage 110%~135%
Protection type: Shut dwon o/p voltage, re-power on to recover
Over Temp. TSW1(Power transistor)When temp. >100 , shut down o/p voltage, re-power on to recover
Working Temp., Humidity -10~+65,20%~90 %RH
Storage Temp., Humidity -20~+85,10%~95 %RH
Vibration 10~200Hz,2G 10min./1cycle, period for 60min, each along X, Y, Z axes
Withstand Voltage I/P-O/P, I/P-FG:1500VAC
Isolation Resistance I/P-O/P, I/P-FG, 100M Ohms / 500VDC
Safety Standard Design refer to UL1950,CSA22.2,IEC60950
EMC Standard Design refer to FCC Part 15 Class A
According to your order, we can provide different cartons for you.
1.All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25 of ambient temperature.
2.Ripple & noise are measured at 20MHz of bandwidth by using a 12twisted pair-wire terminated with a 0.1 &47
3.Tolerance: includes set up tolerance, line regulation and load regulation
4.The power supply is considered a component which will be installed into a final equipment. The final equipment must
be re-confirmed that it still meets EMC directives.
MingWei switching power supply factory is a set design, development, production in one of the high-tech professional manufacturers, the region is the first company to introduce Taiwan manufacturer of switch power supply technology, building in May 2001.
Custom Product Design
Profession in export service from Maker Electric
High quality Product, Affordable Price
Notes on choosing a switching power supply?
To increase the reliability of the S.P.S., we suggest users choose a unit that has a rating of 30% more power than actual need. For example, if the system needs a 100W source, we suggest that users choose a S.P.S. with 130W of output power or more. By doing this, you can effectively boost the reliability of the S.P.S. in your system.Make sure that the model qualifies for the safety standards and EMC regulations you need.
What are switching power supplies?
Switching power supplies input a commercial AC power supply (such as 110 VAC or 220 VAC), uses a high-speed semiconductor switching process to convert the input to high-frequency electric power, and yields a direct current (such as 24 VDC).
What about production process of switching power supply?
