MK-CFS07 2 Meter New Cable Float Switch Liquid Fluid Water Pump Level NO/NC Controller Sensor Cable
$19.12
199 in stock
Description
- Brand Name: makerele
- Certification: CCC,CE,RoHS
- Warranty: 4A
- Switch Type: Knob switch
- Model Number: cable float switch
- Features: 4A
- Item Type: Switches
- DIY Supplies: Plumbing
- Working Temperature: 0~60C(PVC cable), 0~80C(Rubber cable)
- Float Material: PP/PVC
- Cable Length: 2m or customized
- Working pressure: 0.5Mpa
- Rated voltage: AC250V
- Conductor size: 3×0.5mm2 (standard), 3×0.75mm2 , 3×1.0 mm2
- Application: water, sewage, acid-bases liquid
|
||||||||
|
float switch MK-CFS07 uses one-step shaping injection molding with substantial structure, cheap price and long lifetime.
float switch MK-CFS07 uses one-step shaping injection molding with substantial structure, cheap price and long lifetime. It has very good control effect for long distance, multiple level control, submerged pump or liquid with grain or block. Certainly it is also useful for normal liquid. It uses Micro Switch to make connection output. Connection point capacity 10A/250VAC can start the motor equipment directly. It can be regulated freely
and easy to operate, convenient to install, safe and reliable, without maintenance, non-toxic and environment friendly. It can resist sewage so that widely used in pool in resident, factories and mines ect., and ponds, barrel, manger and pot with oil, acid and alkali as well as the vessel with high viscosity and suspended substance.
Product Name | float switch MK-CFS07 |
Electrical rate | AC250V/4A |
Contact Mode | SPDT, NO, NC |
Working Temperature | 0~60C(PVC cable), 0~80C(Rubber cable) |
Protection grade | IP 68 |
Float Material | PP/PVC |
Application | water, sewage, acid-bases liquid |
Working Pressure | 0.5Mpa |
Cable | Material: PVC/rubber Length: 2m 3m 4m 5m 10m; length could be customized Conductor size: 3×0.5mm2 (standard) 3×0.75mm2 3×1.0 mm2 |
Installation Method | throw-in type vertical installation |
-
1. Item will be shipped within 5-7 business days.
-
2. Delivery Time:
-
—-Via Air: Generally 1-3 working days
-
—-Via Express: Generally 3-7 working days.
-
—-Via China Post Air Mail: Generally 15-25 working days
-
—-Via Sea: According to the order.
-
3.If you have not received your shipment within 30 days from payment,Please contact with us,We will track the shipment and get back to you as soon as possible with a reply.
Maker Industrial and Trading Company started to run businiess since 2006, which is located in Wenzhou Yueqing – The world-famous city for low-voltage electric apparatus.
-
Custom Product Design
-
OEM/ODM
-
Profession in export service from Maker Electric
-
High quality Product, Affordable Price
What about float switch?
A float switch is a device used to detect the level of liquid within a tank. The switch may be used in a pump, an indicator, an alarm, or other devices.
Float switches range from small to large and may be as simple as a mercury switch inside a hinged float or as complex as a series of optical or conductance sensors producing discrete outputs as the liquid reaches many different levels within the tank. Perhaps the most common type of float switch is simply a float raising a rod that actuates a microswitch.
A very common application is in sump pumps and condensate pumps where the switch detects the rising level of liquid in the sump or tank and energizes an electrical pump which then pumps liquid out until the level of the liquid has been substantially reduced, at which point the pump is switched off again. Float switches are often adjustable and can include substantial hysteresis. That is, the switch’s “turn on” point may be much higher than the “shut off” point. This minimizes the on-off cycling of the associated pump.
Some float switches contain a two-stage switch. As liquid rises to the trigger point of the first stage, the associated pump is activated. If the liquid continues to rise (perhaps because the pump has failed or its discharge is blocked), the second stage will be triggered. This stage may switch off the source of the liquid being pumped, trigger an alarm, or both.
