L701 CN101A 16A Digital Time Switch Weekly Programmable Electronic Timer AC 220V 110V AC/DC 24V 12V Makerele

Description

• Brand Name: makerele
• Model Number: Time Switch L701
• Theory: Counter
• Usage: Time switch
• Voltage: 12V/24V/110V/220V

L701 CN101A 16A Digital Time Switch Weekly Programmable Electronic Timer AC 220V 110V AC/DC 24V 12V Makerele



Description:

Model number	L701
Supply voltage	220Vac, 110Vac, 50/60Hz; 12Vdc/ac, 24Vdc/ac
Power consumption	2W max
Error correction	1s/days (25°C)
Setting method	Touch switch
Indication method	LCD
Time range	1min to 168h
Power reserve	60 days (When you receive it, it don’t show digits, you can connect it to power, will display again)
Inner battery	1.2V40Ma (Rechargeable)
ON/OFF operation	16 ON/OFF (day/week)
Matched accessories	Terminal wires, Mounting panel
External dimensions	60x60x32 mm
Mechanical life	1×107
Electrical life	1×107
Operating temperature	-20 to 55 °C
Operating humidity	35-85% RH max, non-condensing
Alias name	L701 electronic timer
